50mm Square Axle – 3t Unbraked Land Cruiser

SKU: N/A Categories: Axles - Unbraked, Axles Brand: Couplemate

Price

$800.00 Inc.GST

Stud Pattern (PCD)

Clear

50mm Square Axle - 3t Unbraked Land Cruiser

Face-to-Face Length.(Required)

Enter the Face-to-Face length of your axle. (mm).

Please enter a number from 1000 to 2400.

Shipping

Select delivery location

This 50mm Square 3t Unbraked Axle is an ultra-heavy-duty solution designed for the most demanding trailer applications.

Engineered to handle a massive 3,000kg (3t) rating, this axle is the perfect foundation for heavy plant trailers, livestock hauliers, and specialised machinery trailers where independent braking is managed by other axles in a multi-axle setup.

Product Overview

When 2-tonne axles aren’t enough, this 3t square beam provides the ultimate in structural integrity. Manufactured from premium, high-tensile K1045 steel, it features oversized spindles specifically designed to accommodate 3-tonne bearing sets. Available in both 5-stud and 6-stud Land Cruiser patterns, it allows you to match the heavy-duty rims and tyres required for 3,000kg loads.

Key Features

Extreme Load Capacity: Rated for 3,000kg (3t), making it one of the strongest unbraked axle options available for custom trailer builds.
Solid 50mm Square Beam: Forged from structural-grade K1045 steel to resist bowing and torsional stress under maximum weight.
3t Specific Spindles: Features precision-machined, oversized spindles designed to house large-diameter 3t tapered roller bearings.
LandCruiser Stud Patterns: Choice of 5-stud or 6-stud (139.7mm PCD) patterns, pre-pressed with high-tensile 5/8″ or 1/2″ studs to suit off-road 4WD wheels.
Lazy Hub Configuration: Supplied with heavy-duty “lazy” hubs (unbraked), providing a clean and simplified setup for tandem or tri-axle trailers.

Technical Specifications

Axle Profile: 50mm Solid Square
Load Rating: 3,000kg (3t)
Bearing Set: 3t Tapered Roller (Inner: 30210 | Outer: 15123/245 — please verify specific kit)
Stud Patterns: 5-Stud LandCruiser or 6-Stud LandCruiser
Material: K1045 High-Tensile Steel
Finish: Natural Steel (ready for custom coating or galvanising)

Why Choose a 3t Square Axle?

Standard 50mm axles are typically capped at 2,250kg. This 3t version utilises specialised heat-treatment and larger spindle diameters to bridge the gap for heavy-duty industrial and agricultural use. It ensures your trailer chassis remains stable and your bearings stay cool even under extreme stress.

There are no FAQs for this product.

Additional information

Weight	80 kg
Dimensions	40 × 240 × 40 cm
Stud Pattern (PCD)	5 Stud Landcruiser (5 x 150mm), 6 Stud Landcruiser (6 x 139.7mm)
