Trojan Hydraulic Disc Caliper Spare Parts
Trojan hydraulic disc caliper spare parts to suit 10-inch and 12-inch Trojan disc rotors. INterchange disc pads and bleed screws with other brands like Alko.
These are cast in SG iron and are Electro Zinc Plated for protection against corrosion. Trojan calipers are fitted with a Phenolic piston which is a high strength, non-rusting material. Fittings, such as slide pins and bleed screws, are brass, while other fittings are Stainless Steel.
- 10-inch and 12-inch disc rotors
- 1500kg per axle with 225mm rotors
- 2000kg per axle with 275mm rotors
- Suitable for disc thickness from 10mm to 15mm
The latest Trojan hydraulic caliper mounts onto a threaded anchor plate.
Hydraulic Park Brake Handles
Trojan park brake handles secure your boat trailer when parked. Fit all existing hydraulic Trojan calipers.
In Australia, park brake handles are not a mandatory requirement on boat trailers. However, if you have a $100,000 boat, adding a hand brake handle makes sense to prevent the boat trailer from rolling away.
Trojan caliper slide bolts are factory secured with locktite. Further, we do not recommend installing park brake handles as a DIY. Instead, have your local trailer or boat repairer install this device for you.
Trojan recommends the two stainless screws provided with the park brake handle be locktited into position. This procedure returns the caliper to the manufacturer's requirements.
Note1: It also fits Alko hydraulic calipers, provided you replace the Alko slide pins with Trojan slide pins.
note2: Install park brake at the rear of the rotor.
Replacement Trojan Spare Parts
- Dacromet Caliper incl pads
- The Stainless Caliper includes stainless brake pads, bolts and copper washers.
- Standard Hydraulic Disc Pads, click here.
- Trojan Stainless Disc Brake Pads
- Replacement Hydraulic Phenolic Picton (loose) MK3 1978 -ONWARDS
- Replacement Slides (2 pcs)
- Hydraulic Bleed Nippled (1 pcs)
- Hydraulic Park Brake Handles
Boat trailer parts for Trojan Mark 5, 6 and 7 are out of production.
Trailer weights exceeding 2000 kg require independent control and breakaway facility, causing the brake activation in emergencies.
Tip: When changing or checking disc pads, squeeze the piston home a little by applying a G clamp to the piston.
As a result, this procedure will give you extra room to insert the disc pads.
Further, when inserting a piston, apply a small amount of silicone lubricant to the piston. Silicone lubricant does not contaminate hydraulic brake fluid like grease.
Trojan Hydraulic Disc Caliper Parts
Additional information
Weight | N/A |
---|---|
Dimensions | N/A |
Trojan Hydraulic Parts | Left Hand Hydraulic Caliper Park Brake, Right Hand Hydraulic Caliper Park Brake, Stainless Caliper Pad, Trojan Stainless Caliper, Trojan Dacromet Caliper, Caliper Slide Kit, Hydraulic Bleed Nipple, Replacement Piston |
