AL-KO Coupling Trigger Spring Kit
Price
$13.50 Inc.GST
Shipping
Genuine AL-KO Coupling Trigger Replacement Kit (Part No. 610909)
The AL-KO Coupling Trigger Replacement Kit (Part No. 610909) is an essential maintenance set that restores the locking function of your trailer coupling. This genuine AL-KO International Pty Ltd kit provides a cost-effective way to replace weathered or damaged components without replacing the entire coupling body.
Product Overview
This comprehensive kit is engineered to fit a wide variety of 50mm ball couplings, including Electric, Override (Braked), and Snap-On (Fixed) models. Over years of use, the internal trigger spring can weaken from exposure, or the roll pin may wear, leading to difficult engagement or unsafe latching. Replacing these parts ensures a crisp, secure “click” every time you hitch up.
Key Features
- Complete Replacement Set: Includes a high-strength trigger, a tension-matched spring, and a precision roll pin for a total refresh of your latching mechanism.
- Universal Compatibility: Specifically designed for AL-KO International Pty Ltd snap-on and plunger-style couplings commonly used on caravans, boat trailers, and utility trailers.
- Durable Materials: The heavy-duty component layout features a roll pin made from high-strength spring steel with a protective zinc-plated finish for superior corrosion resistance in marine and outdoor environments.
- Safety Assurance: Maintains strict compliance with Australian Design Rules (ADR) by ensuring the secondary locking mechanism operates exactly as intended.
Specifications
- AL-KO Kit Part Number: 610909 (Skin Pack alternatives match layout dimensions under catalogue sequence 611009)
- Roll Pin Dimensions: 1/4″ Diameter x 7/8″ Length
- Suits Ball Size: 50mm
- Material: Zinc-Plated Steel and High-Quality Spring Steel
- Approximate Weight: 0.05 kg- 0.1 kg
Installation & Maintenance
Secure the trigger to the coupling body using the included roll pin. For smooth operation, AL-KO recommends regular checks and applying grease through the designated nipples, as detailed in official manufacturer documentation. If you are also servicing your suspension, refer to the official alignment guides for correct pin and hanger positioning.
Compatible Couplings
- 2000kg Override Coupling
- AL-KO 3500kg 50mm Ball Coupling, CTA-060191
- 2.0t x 50mm Ball Coupling w/ 3 Bolt Holes
- 2t Trailer Coupling x 50mm Ball Two-Hole
Frequently Asked Questions
- How do I know if this trigger fits my trailer? This kit only fits genuine AL-KO couplings. Check for the stamped AL-KO logo on your hitch body before you buy.
- Does the kit include the main mounting pin? Yes. The pack comes with a new spring, roll pin, and trigger lever for a full repair.
- Can I install this part myself? You can fit it with basic hand tools. However, you must test the locking mechanism thoroughly before towing.
Do’s and Don’ts
- DO apply a small amount of heavy-duty grease to the pivot pin during assembly.
- DO block the trailer wheels safely before starting any repair work.
- DO inspect the main hitch ball socket for excessive wear while the trigger is off.
- DON’T reuse the old roll pin because old pins lose their tension and can fail.
- DON’T use a damaged hitch if the new trigger fails to click into place tightly.
- DON’T over-tighten the components or force the trigger if it feels jammed.
Additional information
| Weight | 0.1 kg |
|---|---|
| Dimensions | 20 × 15 × 3 cm |
