Understanding your Stud Pattern (PCD) is crucial when searching for spare wheel parts like rims or hubs for your trailer or caravan.
Correctly identifying the PCD prevents the purchase of incompatible components, which can save money by avoiding the need for returns or replacements. It also ensures that investments in wheel-related upgrades or replacements are effective.
If you need to replace a wheel or tire while on the road, knowing your caravan’s PCD can be a lifesaver. It enables you to quickly find the right replacement part, reducing downtime and potential inconveniences during your travels.
To begin, let’s clarify the meaning of PCD:
PCD Meaning
PCD stands for “pitch circle diameter,” which denotes the spacing between your wheel studs.
Stud patterns, often referred to as bolt patterns, bolt circles, lug patterns, or PCDs (pitch circle diameters), are primarily determined by the diameter of a circle that passes through the centre of a wheel’s stud holes. Typically, wheels come with 4, 5, or 6 stud holes. This diameter is the foundational element for identifying your stud pattern.
Download a copy of the Couplemate™️ Guide to Trailer Stud Patterns.
Converting Stud Centre to PCD Measurements
While you can simply compare stud centres to work our your PCD, there is a formula used to work out PCD.
PCD Formula is as below:
- 4 Stud Formula = STUD / 0.70711
- 5 Stud Formula = STUD / 0.5878
- 6 Stud Formula = STUD / 0.5
Common Caravan & Trailer Stud Pattern
Common Stud Patterns: 4 Studs
Name | PCD | Stud Centre | Thread Types |
| Barina, Lancer | 4 x 100mm | 70.71mm | 7/16″ UNF |
| Cortina | 4 x 107.95mm | 76.33mm | 7/16″ UNF |
Common Stud Patterns: 5 Studs
Name | PCD | Stud Centre | Thread Types |
| Holden HQ | 5 x 120.65mm | 70.92mm | 7/16″ UNF |
| Holden HT, Torana | 5 x 107.95mm | 63.45mm | 7/16″ UNF |
| Commodore | 5 x 120.00mm | 70.55mm | 7/16″ UNF |
| Landcruiser 100 Series | 5 x 150.00mm | 88.17mm | 9/16″ UNF, M14 x 1.5 Pitch |
| Ford, Mazda, Subaru | 5 x 114.3mm | 67.19mm | 1/2″ UNF |
Common Stud Patterns: 6 Studs
Name | PCD | Stud Centre | Thread Types |
| Nissan Navara (2005 onwards) | 6 x 114.30mm | 57.25mm | 1/2″ UNF, M12 x 1.5 Pitch |
| 2021 Toyota HiAce | 6 x 130.00mm | 65.00mm | M14 x 1.5 Pitch |
| Landcruiser, Nissan (1998-2004) | 6 x 139.70mm | 69.85mm | 1/2″ UNF, M12 1.5 pitch, M14 x 1.5 Pitch |
How can Couplemate Help?
Couplemate stands as a reputable manufacturer and supplier, specialising in top-tier, dependable parts designed to ensure your smooth journey back on the road.
We take pride in our large range of drums, hubs, and disc rotors, all made to meet the highest standards of quality and reliability.
Don’t forget, we’re here to help. If you find yourself in search of a specific stud pattern, or need assistance generally, contact our team and we’ll do our best to assist you.
